Vest Bag (T-shirt Bag)Applicable Bag Types
View All Bag Types →Vest Bag (T-shirt Bag)Production Process
Machine Features
1Auto Computer Control
- Fully automatic, easy operation
2HDPE/LDPE Compatible
- Accepts common poly bag films
3Printed & Unprinted Film
- Works with both printed and plain film
4Heat-Seal Heat-Cut
- Produces T-shirt bags by heat sealing and cutting
ModelKQ-400NT2
Film Web DirectionRight‑to‑Left
Bag‑making ModeHeat‑seal & Hot‑cut
MaterialsHDPE / LDPE
Max. Bag‑making Width360 mm × 2
Max. Bag‑making Length700 mm
Max. Unwinding DiameterΦ800 mm
Film Thickness0.008‑0.05 mm
Bag‑making Speed100‑220 pcs/min
Total Power8.5 kW
Machine Weight1200 kgs
Machine Overall Dimension5400×1750×1250 mm
Configurable and optional features (all adjustable per the KQ-400NT2 design).
Download brochures, certificates and technical files for KQ-400NT2.
