Home / Products / Bag Making Machines / Fully Automatic Bottom-Seal Soft Handle Bag Making Machine

Fully Automatic Bottom-Seal Soft Handle Bag Making Machine

KQ-500ZD

U-shaped compact layout with bottom-seal process and soft-handle heat-sealing. Strong, firm bonding, compatible with multiple films and gusset bags. Stable output, ideal for soft-handle production.

↻
Max Speed50 pcs/min
▣
Bag Width200-480 mm
◎
Film ThicknessHDPE 0.01-0.08 mm
PLC
Control SystemPLC + Touch Screen
KQ-500ZD
KQ-500ZD thumbnail

Product Overview

U-shaped compact layout with bottom-seal process and soft-handle heat-sealing. Strong, firm bonding, compatible with multiple films and gusset bags. Stable output, ideal for soft-handle production.

Applicable Bag Types

View All Bag Types →
hh
hh

Production Process

◉
Film FeedingU-shaped layout, centralized operation
▥
Bottom SealBottom sealing with soft-handle heat system
✂
Gusset FormGusset forming for side expansion
□
Cutting & OutputIndexed cutting and stacking

Machine Features

U-Shaped Layout

1U-Shaped Layout

  • Compact, space-saving, operator-friendly.
Bottom Seal

2Bottom Seal

  • Firm bottom sealing with soft handle.
Gusset Ready

3Gusset Ready

  • Compatible with gusset (windbag) bags.
Stable Output

4Stable Output

  • Smooth running, steady capacity.
ModelKQ-500ZD
SealingBottom seal
Speed50 pcs/min
Bag Width200-480 mm
Bag Length250-600 mm
Film ThicknessHDPE 0.01-0.08 mm
Soft Handle Length360 mm
Line Speed30 m/min
Power~15 kW
Voltage380V 50Hz
Weight2500 kg
Dimension5000×4000×1300 mm
